2000L Beer Brewing Equipment Manufacturer/Beer Making System/Brewery

Contact Now* Send an Inquiry to this supplier.
or
Start Order * Name your price

Browse by Category

Contact us

Jinan Rainbow Machinery Co., Ltd
[China]

Address
88 Huizhan East Road, High-Tech Zone Jinan Shandong
Phone
86-531-66592692
Contact name
Sophie Zhu

Quick Information

  • Brand Name: RAINBOW
  • Place of Origin: China
  • Model Number : RM2000L
  • Processing Types : Alcohol
  • Certificate : CE, ISO9001
  • Material : SUS304 or 316
  • Polishing : 0.4-0.6μm
  • Welding : 100% TIG welding
  • Pressure test : 3 bar

Description

2000L  Beer Brewing Equipment



COMPANY PROFILE:

We, Jinan Rainbow Machinery Co., Ltd  are a professional manufacturer and leading supplier of good quality beer brewing system, ranging from 100L-10000L per patch (used for home, pub/hotel, factory, etc.) at a very competitive price, with product design, production, sales, and installation support.



We have been exporting beer brewing tanks to many places like USA, Canada, Ecuador, Germany, France, Czech Republic, Finland, Norway, Switzerland, Australia, Taiwan....etc.





MAIN CONFIGURATIONS:

This brewhouse system includes 3 tanks(mash tun/lautering tun, brew kettle/whirlpool, hot liquor tank), please check the details in the following chart.

Optional: 1- mash/brew kettle, lauter tun/whirlpool

                  2- mash/brew kettle, lauter tun, whirlpool

                  3- mash tun, lauter tun, brew kettle/whirlpool

                 4- mash tun, lauter tun, brew kettle, whirlpool



This following chart is the 2000L beer brewing system configuration for your reference.

Items

Equipment

Specification

Quantity

(PCS)

Malt miller

Malt miller

300kg/hour

1

Brew house

Mash tun/lautering tun

2000L

1

Brew kettle/whirlpool

2000L

1

Hot liquor tank

2000L

1

Plate heat exchanger

20 m2

1

Pump

3 m³/h

1

Oxygenator



1

Working platform



1

Fermentation

Fermenter

2000L

6

Yeast adding tank

50L

1

Cooling unit

Glycol water tank

4000L

1

Cooling compressor

10hp

2

Water pump

3 m³/h

1

CIP unit

Alkali tank

200L

1

Sterilization tank

200L

1

Pump

3 m³/h

1

Control unit

Siemens PLC controlling system

1

Filter system

Kieselguhr filter machine

500L/H

1

Bright beer tank

2000L

1

Spare parts

All necessary spare parts such as pipes, valves, gauges and clamps…etc

   ♦ providing beer production technology

  ♦  Material: stainless steel 304 or copper

 ♦  Heating source: electricity, gas fired or steam heating



Main features of brewhouse and fermentation:

Brewhouse system:

1) - interior wall stainless steel 304, 3mm;

    - exterior wall stainless steel 304, 2mm

2) - Dome top, top manway with glass

    - Side manway, cone bottom 160 degree

3) - insulation: polyurethane/rockwool 100mm;

     - with inside CIP washing ball

     - raking agitator

    - removable false bottom

    - sparging arm, sight glass

    -Tangential inlet for whirlpool

     -Thermowell for temperature sensor and thermometer....

    -100% TIG welding with pure argon gas shield

    - Interior Finish:Mirror polishing to 0.4~0.6μm without dead corner



Fermentation system:

1) - Interior wall stainless steel 304, 3mm;

      - exterior wall stainless steel 304, 2mm

 2) - Dome top, conical bottom,

     - Side mounted manway

3) - Insulation: polyurethane 100mm

4) - Glycol cooling jackets on both cylinder and cone

5) - Inside 360 degree rotating CIP washing ball;

     - CIP arm

     - Pressure gauge

     - relief&vacuum valve on top

      - sample valve

     - rotating racking arm on cone with butterfly valve

     - thermometer

     -carbonation stone (optional)

    - dry hops port on top

 6)  -100% TIG welding with pure argon gas shield

      -Interior Finish:Mirror polishing to 0.4~0.6μm without dead corner

      -Testing pressure: 3 bar

      -working pressure: 1.5-2 bar



 Spare parts:

-Pipe line for brewhouse

-Butterfly valves

-Sight glass

-Measuring cylinder

-Saccharimeter, 0-10&10-20

-Spent grains harrow

-Steam solenoid valve(if use steam heating method)

-Cooling solenoid valve

-Safety valve for steam

-Relief/vacuum valve for fermenters

-Thermometer

-Pipeline for cooling

-Expansion valve for glycol chiller

-Signal wire

-Cable

-Temperature sensor, PT100



For Your Reference:

1. For electrical elements part, we use SIEMENS, SCHNEIDER, DANFOSS, OMRON, ABB....etc. And also do UL standard



2. We have the capacity of 100L, 200L, 300L, 500L, 1000L, 1200L, 2000L, 3000L, 5000L, 8000L...

    ( 1bbl, 2bbl, 5bbl, 10bbl....) per patch for your reference.

      It can be customized, such as the capacity(dimension can be customized), material,      voltage(like 380v, 50Hz, 3phases), heating source(electric, steam or direct fired heating), etc.



 3. The brewer can also brew draft beer, pale beer, brown beer, stout beer etc,

      to meet different taste of customers.



 OPTIONAL:

 Beer bottling line: bottle washing machine, filling machine, capping machine,

 pasteurization tank, labelling machine.

 Kegs washer and filler.

 Beer kegs(10L,20L,30L,50L...).

 Steam boiler.





2000L complete beer brewing equipment, craft brewery equipment system, beer fermenter tank

2000L complete beer brewing equipment, craft brewery equipment system, beer fermenter tank

2000L complete beer brewing equipment, craft brewery equipment system, beer fermenter tank



2000L complete beer brewing equipment, craft brewery equipment system, beer fermenter tank

2000L complete beer brewing equipment, craft brewery equipment system, beer fermenter tank

2000L complete beer brewing equipment, craft brewery equipment system, beer fermenter tank

2000L complete beer brewing equipment, craft brewery equipment system, beer fermenter tank

2000L complete beer brewing equipment, craft brewery equipment system, beer fermenter tank

2000L complete beer brewing equipment, craft brewery equipment system, beer fermenter tank


Price

  • Price Condition : FOB
  • Price : USD68900 / 1
  • Delivery Port : Qingdao

Packaging & Delivery

  • Delivery Lead Time : 40-45 working days after confirm the order
  • Minimum Order : 1
  • Supply Ability : 20 sets per month
